DOC101681-1- rev.2
21
8 and 13" DIS DDC Control
All intellectual properties belongs to Hatteland Display AS
[S] 6E [W] 51 84 E2 F3
01 39 92 [P]
[S] 6F [R] 6E 84 E4
01 39 03 65 [P]
Red color  Set or Get data length.
Green color  Sub function ID.
Blue color  Set or get data.
 Data setting description
When value is 0 that sensor reaction level is range 1.
When value is 1 that sensor reaction level is range 2.
When value is 2 that sensor reaction level is range 3.
When value is 3 that sensor reaction level is range 4.
When value is 4 that sensor reaction is off.
 ALARM status of Computer side and Video Control
VCP
Code
Sub-F Function Description
D
N
Type
R W
0xF3 0x40 f1) Power OFF --> ON 0 0 WO
0xF3 0x41 f2) Booting 0 0 WO
0xF3 0x42 f3) OS Running 0 0 WO
0xF3 0x43 f4) Application running normal 0 0 WO
0xF3 0x44 f5) Maintenance 0 0 WO
0xF3 0x45 f6) Computer halted 0 0 WO
0xF3 0x46 f7) Computer running in loop 0 0 WO
0xF3 0x47 f8) Shut Down 0 0 WO
0xF3 0x48 f9) Restart 0 0 WO
0xF3 0x49 f10) Sleep Mode 0 0 WO
0xF3 0x4A f11) Low Power 0 0 WO
0xF3 0x4B f12) I/O Grading not ok 0 0 WO
0xF3 0x4C f13) Power ON --> OFF 0 0 WO
3.3.20. Sub-Function: 0x40
– 0x4C Computer state
This part command is follow Hatteland system overview status.
Command example:
 0x40
[S] 6E [W] 51 84 E7 F3
00 22 8D [P]
Red color  set data length.
Green color  Sub function ID.
 0x40
[S] 6E [W] 51 84 E7 F3
00 40 EF [P]
