37
Dimensions in cm
11. Technical Data
The Como, certified in compliance with DIN-EN 13240 : 2001 + A2 2004 and Art.
15 a B-VG (Austria), can only be operated when the fire box is closed; more than
one device can be connected to the chimney.
VKF-No.: 18009
The following data applies to the chimney characteristics in accordance with EN
13384-1 / 2
Combustion Values Wood Briquettes
Nominal Thermal Output 7 7 kW
Efficiency 82 81 %
Particulate 36 35 mg/Nm³
CO content at 13% O2 938 838 mg/m³
Waste Gas Mass Flow Rate 7 7 g/s
Waste Gas Outlet Temp. 300 300 ˚C
Min. Supply Pressure at Nominal Thermal Output 11 11 Pa
Depending on the insulation of the building, the nominal thermal output of 7 kW
indicated on 25 bis 95 m² (subject to change).
Dimensions: Height Width Depth
Stove
117,5 cm 62 cm 57 cm
Fire box 27,5 cm 36 cm 33 cm
Weight (ceramic / soapstone): 215 / 271 kg
Flue pipe diameter 15 cm
Pipe diameter of Hase ventilation system* 10 cm
* For separate air supply in low-energy houses and insufficient combustion air
supply in the room where the stove is installed.
Front view Side view
Top view
Aufsicht
Keramik/Naturstein:
Stove
height:
117,5
Height for rear installation: 99 Height for top installation: 112
Height for the inst. of Hase air system: 17
17,5
62
57
5,5 Ш 17
