Combination installations, Planning guide, Classic wall oven/ microwave

background image

PLANNING

GUIDE

Web: http://www.Dacor.com

Corporate Phone: 800-793-0093

Specifications are subject to change without notice.

See installation instructions for additional details.

CI.13

Classic wall oven/

microwave

CombINATIoN INsTALLATIoNs

“C”

16 3/4"

(425mm)

1 3/4"

(44mm)

Min.

“B”

“A”

120V

Microwave

Receptacle

240V

Wall Oven

Junction Box

1

1

1“ (25mm) Min.

19 1/8"

(486mm)

1 1/2"

(38mm)

Min.

“B”

“A”

120V

Microwave

Receptacle

240V

Wall Oven

Junction Box

“C”

1

1

1“ (25mm) Min.

CUToUT DImENsIoNs

DmT2420 sHowN

CUToUT DImENsIoNs

DCm24 sHowN

Wall Oven

Models

“B” Cutout

Width

C” Cutout

Height

Oven

Overlays

Single 27”

25 1/2” (648mm)

27 3/8” (695mm)

3/4” (19mm)

Each Side;

15/16” (24mm) Top;

1/16” (1mm) Bottom

Single 30”

28 1/2” (724mm)

Single 36”

34 1/2” (876mm) 27 1/8” (689mm)

Double 27”

25 1/2” (648mm)

49 1/16”

(1246mm)

Double 30”

28 1/2” (724mm)

Microwave

Model No.

“A” Cutout Width

Trim Kit Overlays

DMT2420 w/Trim Kit

24 3/8” (619mm)

5/8” (16mm) Top;

3/4” (19mm) Bottom

DCM24 w/ACTK27

25 1/4” (641mm)

DCM24 w/ACTK30

28 1/4” (718mm)

DCM24 w/ ACTK36

25” (635mm)

NOTE:

1. 3/4” (19mm) support platform (flush with cutout).

1/1

062805
