Hanna Instruments HI 83730 User Manual

Ism peroxide value of edible oils, Instruction manual

www.hannainst.com

Instruction manual

HI 83730

ISM

peroxide value

of edible oils

Peroxides are the primary products of oil oxidation. Their identi-
fication gives useful informations about oil conservation and
rancidity. HI 83730

HI 83730

HI 83730 allows fast and simple analyses of perox-

ides in oil in accordance with the EC 2568/91 method.
Oil peroxides content
< 10 meq O

/kg

excellent conservation

10-15 meq O

/kg

good conservation

< 10 meq O

/kg

refined oil

> 20 meq O

/kg

rancid oil

General description

Warranty

Preliminary examination

Significance and use

Specifications

Range

0.0 to 25.0 meq O

/kg

Resolution

0.5 meq O

/kg

Accuracy

± 0.5 meq O

/kg

Light source

tungsten lamp with narrow band
interference filter @ 466 nm

Method

adaptation of EC 2568/91 method
and following amendments

Light detector

silicon photocell

Environment

0 to 50 °C (32 to 122°F); max 95% RH

Power supply

4x1.5 V AA or adapter 12 Vdc

Auto shut-off

after 15 min of non use

Weight/dimensions

512 g; 224 x 87 x 77 mm

Required reagents

Required reagents
Code

Description

Quantity/test

HI 83730A-0

Peroxide reagent A

1 vial

HI 83730B-0

Peroxide reagent B

1 packet

Functional description

Chemical reaction

Guide to display codes

The reaction between sample and reagent causes a color variation,
proportional to the peroxide content expressed in meq O

/kg.

IST83730 12/05

Indicates that the instrument is in a
ready state and waiting for the next
command (Timer or Zero).

These prompts indicate the type of power
supply: “Line” (if the external power
supply is used) or the battery level.

This prompt appears for a few seconds
each time the instrument is turned ON.

The instrument is zeroed and a
measurement can be made.

Indicates that the meter is making a
measurement.

Indicates that the meter is performing a
zero measurement. The light intensity is
automatically re-adjusted if necessary.

Batteries voltage is getting low and the
batteries need to be replaced.

The meter has lost its configuration. Contact
your dealer or the nearest Hanna Customer
Service Center.
“Light high”: there is too much light to
perform a measurement. Please check the
preparation of the zero cuvet.

Indicates that the batteries are dead and
must be replaced. After this message
appears, the instrument is switched off.
Change the batteries and restart the meter.

“Light low”: there is not enough light to
perform a measurement. Please check the
preparation of the zero cuvet.

After TIMER is pressed, a blinking
hourglass icon appears and the display
shows a 6 minutes countdown.

Error messages

Dear Customer,
Thank you for choosing a Hanna product. This manual will provide
you with the necessary information for the correct use of the
instrument. Please read it carefully before using the meter. If you
need additional technical information, do not hesitate to e-mail
us at [email protected].
This instrument is in compliance with directives.

Please examine this product carefully. Make sure that the instrument
is not damaged. If any damage occurred during shipment, please
notify your Dealer.
Each HI 83730 Ion Selective Meter is supplied complete with:

• reagents for 10 tests;
• four graduated 1 mL syringes, scissors, tissue for wiping

vials;

• four 1,5V AA batteries and AC Adapter
• instruction manual and rigid carrying case

Note: save all packing material until you are sure that the

instrument works correctly. Any defective item must be
returned in its original packing.

The HI 83730 is an auto-diagnostic portable microprocessor
meter that benefits from Hanna’s years of experience as a
manufacturer of analytical instruments. It has an advanced
optical system based on a special tungsten lamp and a narrow
band interference filter that allows most accurate and repeatable
readings. All instruments are factory calibrated.
The auto-diagnostic feature of this meter ensures always optimal
measurement conditions to ensure most precise readings. The
light level is automatically adjusted each time a zero-measurement
is made, and the temperature of the lamp is controlled to avoid
overheating.

1) Lid
2) Cuvet holder
3) Liquid Crystal Display (LCD)

4) ON/OFF key, to turn the

meter on and off

5) ZERO key, to zero the meter
6) TIMER key, to active a

countdown

7) READ key, to perform

measurement

8) Power socket 12V to

20 V dc 2.5 Watt

HI 83730

HI 83730 is warranted for two years against defects in workmanship
and materials when used for its intended purpose and maintained
according to the instructions.
This warranty is limited to repair or replacement free of charge.
Damages due to accident, misuse, tampering or lack of prescribed
maintenance are not covered.
If service is required, contact your dealer. If under warranty, report
the model number, date of purchase, serial number and the
nature of the failure. If the repair is not covered by the warranty,
you will be notified of the charges incurred.
If the instrument is to be returned to Hanna Instruments, first
obtain a Returned Goods Authorization Number from the Customer
Service Department and then send it with shipment costs prepaid.
When shipping any instrument, make sure it is properly packaged
for complete protection.
To validate your warranty, fill out and return the enclosed warranty
card within 14 days from the date of purchase.
