7

FUNCTIONAL DESCRIPTION

FRONT PANEL

REAR PANEL

INSTRUMENT DESCRIPTION

1) Graphic LCD
2) Functional keys
3) Keypad
4) Electrode holder

5) Ammonia electrode

10)

BNC electrode connector

6) Temperature probe

11)

Power switch

7) Electrode holder

12)

Fuse

8) Reference socket

13)

Power cable connector

9) Temperature probe socket
