Hanna Instruments HI 931002 User Manual

Page 2

PRELIMINARY EXAMINATION

Remove the instrument from the packing material and examine it
carefully to make sure that no damage has occurred during shipment.
If noticeable damage is found, immediately notify your Dealer.
In addition to this manual you should find the following items:
• HI 931002 meter;
• 12 VDC power adapter (HI710005 or HI710006);
• 1 m (3.3') connection cables;
• 9 V battery.
Note: Save all packing material until the instrument has been ob-

served to function correctly. All defective items must be returned
to the Dealer in their original packing.

GENERAL DESCRIPTION

HI 931002 is a portable 4-20 mA simulator, ammeter and calibrator
designed specifically for monitoring and regulating a 4-20 mA current
loop from practically any process meter with or without voltage source.
Four operational modes are provided:
1) Passive Drive/Calibrator Mode. HI 931002 can be set to simu-
late 4-20 mA current values and the user can then adjust the process
meter accordingly.
2) Active Drive/Simulator Mode. HI 931002 simulates the correct
values as above in addition to providing power to the current loop.
Power is provided through an external adapter (included) which is
connected to the simulator. This mode is ideal for calibrating chart
recorders, pressure transducers or current indicators.
3) Passive Measurement/Tester Mode. HI 931002 practically be-
comes an Ammeter. It measures and displays the mA (or pH) values
transmitted by the process meter.
4) Active Measurement/Tester Mode. Same as point 3 in addition
to providing voltage to the 4-20 mA bus.
HI 931002 can practically measure incoming current, provide power
and simulate 4-20 mA output to calibrate almost any process meter.
A large LCD shows current values. You can select between drive and
measurement modes through a switch on the front panel and two
dials that allow for quick adjustment of the current.

Dear Customer,
Thank you for choosing a Hanna Instruments Product.
Please read this instruction manual carefully before using the instru-
ment.
This manual will provide you with all the necessary information for
the correct use of the instrument, as well as a precise idea of its
versatility in a wide range of applications.
These instruments are in compliance with directives EN 50081-1
and EN 50082-1.

PRELIMINARY EXAMINATION ....................................................... 3
GENERAL DESCRIPTION .............................................................. 3
FUNCTIONAL DESCRIPTION AND SPECIFICATIONS HI931002 ........ 4
OPERATIONAL GUIDE ................................................................. 5
mA - pH RELATION .................................................................... 9
BATTERY REPLACEMENT.............................................................. 9
FUSE REPLACEMENT .................................................................. 9
ACCESSORIES .......................................................................... 10
WARRANTY .............................................................................. 10
CE DECLARATION OF CONFORMITY ............................................ 11

TABLE OF CONTENTS

ISO 9000 Certified
Company since 1992
