FUNCTIONAL DESCRIPTION
1) Connector for temperature probe
2) Connector for reference electrode
3) BNC connector for fluoride electrode
4) Liquid Crystal Display (LCD)
5) ON/OFF button
6) CAL button
7) STD button
8) CFM button
SPECIFICATIONS
Range 0.050 to 0.500 mg/L (ppm) / 0.50 to 5.00 mg/L
5.0 to 50.0 mg/L / 50 to 500 mg/L / 0.50 to 1.90 g/L Fluoride
0.0 to 50.0°C
Resolution 0.001 mg/L (ppm) / 0.01 mg/L
0.1 mg/L / 1 mg/L / 0.01 g/L Fluoride
0.1°C
Accuracy ±5% of reading or ±0.02 ppm Fluoride
(with ±3°C from calibration temperature)
±0.5 °C
Typical EMC Deviation ± 2% FS (Fluoride) / ±0.5°C
Calibration Automatic, 1 or 2 point at
1 mg/L, 2 mg/L, 10 mg/L, 100 mg/L and 1000 mg/L
Temperature Compensation
Automatic, 5 to 35 °C (with temperature probe)
Electrodes HI 4010 fluoride electrode with BNC and 1 m (3.3') cable
HI 5313 reference electrode with 1 m (3.3') cable (not included)
Temperature Probe HI 7662 with 1 m (3.3') cable
Battery Type / Life 4 x 1.5V AA / approx. 120 hours of use
Environment 0 to 50°C (32 to 122°F); RH max 100%
Dimensions 196 x 80 x 60 mm (7.7 x 3.1 x 2.4")
Weight 500 g (1.1 lb.)
