Hanna Instruments pH 209V - Manual (Page 3)

5 4
FUNCTIONAL DESCRIPTION
Range 0.00 to 14.00 pH / ±1999 mV
Resolution 0.01 pH / 1 mV
Accuracy (@20°C) ±0.01 pH / ±1 mV
Typical EMC Deviation ±0.03 pH / ±2 mV
pH Calibration Manual, 2 point, through offset and slope knobs
Temperature Compensation
Manual, from 0 to 100°C (32 to 212°F)
pH Electrode (included)
HI 1048B glass body, double junction,
refillable, with BNC and 1 m (3.3') cable
Input Impedance 10 12 ohm
Power Supply 12 Vdc adapter (included)
Environment 0 to 50°C (32 to 122°F);
RH max 95% non-condensing
Dimensions 240 x 182 x 74 mm (9.4x7.2x2.9")
Weight 1.0 kg (2.2 lb.) - meter only
SPECIFICATIONS
1) Liquid Crystal Display (LCD)
2) pH slope adjustment knob
3) pH offset adjustment knob
4) pH range selection key
5) mV range selection key
6) °C range selection key
7) Temperature setting knob
8) ON/OFF switch
9) Power adapter socket
10) BNC connector for pH (or ORP) electrode
11) Electrode reference socket
