Hamilton Buhl HDV5200 - Manual (Page 6)

5
Section 2
Getting Started
Loading the Battery
Before using the camera, users must load NP 60 Battery.
Follow the arrow direction and slide to eject the battery 1.
cover.
Insert the battery according to the correct polarity marks 2.
( + or -).
Close the battery cover firmly.
3.
Inserting and Removing an SD Card (Optional)
The camera comes with internal memory which allows you to store pictures, movies and music. You can
expand the memory capacity by using an optional SD memory card. To insert a memory card, refer to
the figure as below:
Insert the memory card into the right position. 1.
To remove an installed SD card, press the card inwards 2.
to release it.
When the card pops out, gently remove it from its slot. 3.
Note
When a memory card is fitted, movies and pictures are saved on card rather than on the built-in
memory.
Eject
