UH-1D
3
1.0 Introduction
The UH-1D is a member of the video over twisted pair extension line from Hall
Research. This economical and easy to install extension kit uses only a single UTP
(Cat6) cable to extend Full HD 1080p HDMI signals to over 130 ft (40m),or
720p/1080i to 170 ft (52m). The product is comprised of a sturdy and compact
Sender and a corresponding Receiver.
The UH-1D offers several unique features such as a local HDMI output (loop) on the
Sender for connection to a local monitor, and EDID management capability with
ability to learn and emulate EDID from any display.
In addition to the HDMI video output, the Receiver provides both digital audio
(SPDIF) as well as analog (stereo L/R) outputs for connection to audio equipment.
The UH-1D allows connection of an IR detector and an IR emitter cable to each end.
This provides the ability to extend IR signals in either direction. For example, when
an IR detector is connected to the remote Receiver and IR emitter is connected to the
sender, the user, from the remote TV end, can control the source using an IR remote.
IR cables are sold separately.
The devices have L-shaped brackets on each end for easy surface mounting and they
feature locking HDMI connectors to secure compatible locking cables such as Hall
Research C-HDMI-L series cables.
2.0 Features
• Uses only one Cat5e/6 cable to extend HDMI without compression
• Can extend Full HD (1080p) to 130 ft (40m)
• Provides local HDMI loop-output on the transmitter for connection to local
monitor or to another UH-1D sender
• EDID learn button (to store and emulate EDID from any display)
• Supports HDCP
• Receiver provides both 3.5mm analog and RCA digital audio outputs
• Can extend IR in both directions (IR cables are sold separately)
2.1 Package Contents
1x UH-1D-S (sender)
1x UH-1D-R (receiver)
2x 5vDC power supplies (one for each end)
1x User’s Manual
*All packages are carefully inspected prior to shipment. However if you think that
you are missing an accessory, please contact Hall Research Support for further
assistance.
