Grandview CB-UX(Portable Self-Stand Series) - Manual (Page 3)

2 5
3. Pull up the handle while using the thumb to release the tube lock as arrow indicates . ( Figure 6 )
2. Pull up the handle as the arrow indicates below . ( Figure 4 - 5 )
W (mm) L (mm) H (mm) A (mm)
4:3
16:9
B1 (mm)
CB-U70
CB-U80
70"
80"
CB-U70
CB-U80
70"
80"
1422 1067 1582 2400 35
1625 1220 1785 2553 35
1550 871 1710 2204 35
1770 995 1916 2328 28
25
B1
A
L
W
H
L
A
Measurement unit: mm
320mm
1. Put the screen on the ground, in a proper position facing the projector. Turn the feet out until they are
perpendicular to the screen casing . ( Figure 1 - 3 )
Figure 1 Figure 2 Figure 3
Figure 4 Figure 5
Figure 6
Open Screen
Casing Foot
Specifications
Net weight
(kg) Format Model
Specification
(In)
Viewing area Screen dimension
Note: Sizes and specifications are subject to change at any time. Refer to real product for exact data.
The tolerance for L is 5mm.
Front view Top view Side view
Handle
800
