3
1 Barcode Printer
G500 Series
 Open The Printer Cover
 Open The Printing Mechanism
ADJUSTMENT SCREW ( LEFT )
Screw for adjusting the print head pressure
ADJUSTMENT SCREW ( RIGHT )
Screw for adjusting the print head pressure
LABEL SUPPLY MODULE
- LABEL SUPPLY HUB
- LABEL GUIDE PLATES ( SET of 2 ) RIBBON MODULE
- RIBBON FEED MECHANISM
- RIBBON HUB
- EMPTY RIBBON CORE
LABEL GUIDE ( RIGHT )
RELEASE CATCH ( RIGHT )
RIBBON SUPPLY HUB
RELEASE CATCH ( LEFT )
LABEL GUIDE ( LEFT )
PRINTING MECHANISM
PLATEN
LABEL SENSOR
Movable
ADJUSTMENT SCREW
Screw for adjusting
the print line
Barcode Printer
003
