33 105541
OWNER’S MANUAL
PARTS LIST
DIRECT-VENT FIREPLACE
CDV37N(A,B)
CDV41N(A,B)
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 30 of this manual.
KEY
NO.
PART NUMBER DESCRIPTION QTY.
1 104547-02 Top Outer Casing-37" 1
104547-03 Top Outer Casing-41" 1
2 104474-02 Outer Casing-37" 1
104474-03 Outer Casing-41" 1
3 104548-02 Bottom Outer Casing-37" 1
104548-01 Bottom Outer Casing-41" 1
4 104479-14BR Firebox Assembly-37" 1
104479-13BR Firebox Assembly-41" 1
5 M11084-26 Screw, Hex 52
6 M11084-46 Screw, Hex 9
7 102455-04 Louver, Extruded-37" 2
102455-03 Louver, Extruded-41" 2
8 104443-01 Firebox Support, Right 1
9 104486-01 Firebox Support, Left 1
10 104482-01 Switch Bracket 1
11 104483-01 Floor Mounting Bracket 2
12 104491-01 Relief Cover 1
13 104518-01 Relief Cover Gasket 1
14 104527-01 Relief Spring 2
15 104528-01 Relief Washer 2
16 104537-01 Valve Bracket 1
17 104496-01 SIT Valve, Natural 1
18 104497-01 SIT Pilot, Natural 1
19 104498-01 Thermocouple 1
20 104499-01 Thermopile 1
21 104500-01 Piezo Ignitor 1
22 104501-01 Ignitor Bracket 1
23 104502-01 Ignitor Screw 1
24 104503-01 Ignitor Wire 1
25 104571-01 Front Burner, Natural-37" 1
104606-01 Front Burner, Natural-41" 1
26 104572-01 Rear Burner, Natural-37" 1
104505-01 Rear Burner, Natural-41" 1
27 104488-01 Burner Manifold 1
28 104489-01 Burner Gasket 1
29 104506-04 Orifice-37" 1
104506-05 Orifice-41" 1
30 104506-05 Orifice 1
31 104507-01 Brass Elbow 1
32 104574-01 Brass Elbow 1
33 104508-01 Brass Fitting 3
34 104608-02 Aluminum Tubing Assy-37" 1
104608-01 Aluminum Tubing Assy-41" 1
35 104510-01 Pilot Tubing Assy 1
36 101628-04 Flexible Connector 1
37 103823-02 Remote Set 1
38 104972-01 Burner Bracket 2
39 104628-01 Log Set - 37" 1
104631-01 Log Set - 41" 1
39-1 104883-02 Rear Log - 37" 1
104883-01 Rear Log - 41" 1
39-2 104884-02 Front Log - 37" 1
104884-01 Front Log - 41" 1
39-3 104885-02 Crossover Log - 37" 1
104885-01 Crossover Log - 41" 1
40 M10908-2 Screw 6
41 M12461-73 Screw 3
42 H5C4-20B Bolt 2
43 NTC-4C Locknut 2
44 M12461-26 Screw 4
45 104569-02CJ Grate Assy-37" 1
104569-01CJ Grate Assy-41" 1
46 105775-07 Glass Door Assy-37" 1
105775-05 Glass Door Assy-41" 1
47 104955-01 Nut 3
48 104576-02CK Front Assembly-37" 1
104576-03CK Front Assembly-41" 1
49 104615-02 Insulation-37" 1
105628-01 Insulation-41" 1
50 104313-01 Hinge, Pin 1
51 104313-02 Hinge, Pin 1
52 103769-01 Duplex Outlet 1
53 104602-01 Duplex Outlet Cover 1
54 104542-04 Brass Plated Trim-37" 2
104542-03 Brass Plated Trim-41" 2
55 104565-01 Magnet 4
56 104954-01 Screw 3
57 104963-01 Washer 3
GA6060 Lava Rock 1
104529-01 Ember Material 1
104512-01 Ball Valve 1
KEY
NO.
PART NUMBER DESCRIPTION QTY.
PARTS INCLUDED - NOT SHOWN
