1.9.3
Request System Status
This status requests the DVD playing information .
byte \ bit
7
6
5
4
3
2
1
0
0
STX ( 02h )
1
Command code ( ' 0 ')
2
Reserve ( 00h )
3
Reserve ( 00h )
4
Reserve ( 00h )
5
Reserve ( 00h )
6
ETX ( 03h )
7
BCCH ( high-level )
8
BCCL ( low-level )
1)
Answers returned
byte \ bit
7
6
5
4
3
2
1
0
0
STX ( 02h )
1
Reply code ( ' 0 ')
2
Answer code
3
Disc type code ( *1 )
4
Audio format code ( *2 )
5
Audio channel code ( *3 )
6
Dialog code ( *4 )
7
Subtitle code ( *5 )
8
Angle code ( *6 )
9
Status code
10
Play mode code ( *7 )
11
Group or Title number information (10 digits)
12
Group or Title number information (1 digits)
13
Track or Chapter number information (100 digits)
14
Track or Chapter number information (10 digits)
15
Track or Chapter number information (1 digits)
16
Time mode ( *8 )
17
Elapsed time (hour, 10 digits)
18
Elapsed time (hour, 1 digits)
19
Elapsed time (minutes, 10 digits)
20
Elapsed time (minutes, 1 digits)
21
Elapsed time (second, 10 digits)
22
Elapsed time (second, 1 digits)
23
ETX ( 03h )
24
BCCH ( high-level )
25
BCCL ( low-level )
(*1) Disc type code (*2) Audio format code (*3) Audio channel code (*4) Dialog
code
Code
Disc Type
Code
Audio Format
Code
Audio Channel
Code
Dialog
31h (1) DVD VIDEO 31h (1) DOLBY DIGITAL 31h (1)
1 ch
31h (1)
JPN
32h (2) DVD AUDIO 32h (2)
DTS
32h (2)
2 ch
32h (2)
ENG
33h (3)
VCD
33h (3)
MPEG
33h (3)
2.1 ch
33h (3)
FRA
34h (4)
CD-DA
34h (4)
LPCM
34h (4)
3 ch
34h (4)
DEU
35h (5)
ROM
35h (5)
PPCM
35h (5)
3.1 ch
35h (5)
ITA
36h (6) UNKNOWN 36h (6)
UNKNOWN
36h (6)
4 ch
36h (6)
ESP
37h (7)
SACD
37h (7)
DSD
37h (7)
4.1 ch
37h (7)
NLD
38h (8)
DVD-VR
38h (8)
5 ch
38h (8)
CHI
39h (9)
5.1 ch
39h (9)
RUS
3Ah (: )
6 ch
3Ah( : )
KOR
3Bh (;) L /R (CD/VCD/MP3) 3Bh( ; ) UNKNOWN
3Ch (<) R (CD/CD/MP3)
3Dh (=) L (CD/VCD/MP3)
3Eh (>)
UNKNOWN
