Page 13
11
Setting up
(a) Screen size
[inch (m)]
(b) Projection distance
[m (inch)]
(c) Screen height [cm (inch)]
down
up
40
(1.0)
1.5
(57)
8.7
(3)
52.3
(21)
50
(1.3)
1.8
(72)
10.9
(4)
65.3
(26)
60
(1.5)
2.2
(87)
13.1
(5)
78.4
(31)
70
(1.8)
2.6
(101)
15.2
(6)
91.4
(36)
80
(2.0)
2.9
(116)
17.4
(7)
104.5
(41)
90
(2.3)
3.3
(130)
19.6
(8)
117.6
(46)
100
(2.5)
3.7
(145)
21.8
(9)
130.6
(51)
120
(3.0)
4.4
(174)
26.1
(10)
156.8
(62)
150
(3.8)
5.5
(218)
32.7
(13)
195.9
(77)
200
(5.1)
7.4
(291)
43.5
(17)
261.3 (103)
(a) Screen size
[inch (m)]
(b) Projection distance
[m (inch)]
(c) Screen height [cm (inch)]
down
up
40
(1.0)
1.6
(63)
1.2
(0)
48.6
(19)
50
(1.3)
2.0
(78)
1.5
(1)
60.8
(24)
60
(1.5)
2.4
(94)
1.8
(1)
72.9
(29)
70
(1.8)
2.8
(110)
2.1
(1)
85.1
(34)
80
(2.0)
3.2
(126)
2.4
(1)
97.2
(38)
90
(2.3)
3.6
(142)
2.7
(1)
109.4
(43)
100
(2.5)
4.0
(158)
3.0
(1)
121.6
(48)
120
(3.0)
4.8
(190)
3.6
(1)
145.9
(57)
150
(3.8)
6.0
(238)
4.4
(2)
182.3
(72)
200
(5.1)
8.1
(317)
5.9
(2)
243.1
(96)
Arrangement
Refer to the illustrations and tables below
to determine the screen size and projection
distance.
The values shown in the table are calculated
(±3%) for a full size screen: 800x600
At 16:9 screen
At 4:3 screen
4:3
(a)
16:9
(a)
(c) up
(c) down
(b)
