Rotating
Seal
Fixed
Seal
F
31.
33.
32.
34.
Undo the connection by pulling the two connectors apart.
Remove the upper bearing housing.
Use a mallet to remove the upper bearing housing.
Remove the plastic electric wire protection.
23.
Pull the tool holding the mechanical seal upwards to the
end of the shaft.
24.
Remove the alluminum seal housing.
25.
27.
26.
28.
Pull out the rotor.
Remove the screw from the upper motor cover.
Turn the motor housing up side down to remove the
compensating washer “F”.
Use a mallet to remove the upper stainless steel cover.
29. 30.
Remove the cover of the upper bearing housing. Remove the plastic protection of the condensator.
