E-Tech ES series 5" close-coupled pumps - Manual (Page 2)

2/20 3/20
It is our policy to continuously develop and improve our products, therefore, we reserve the right to amend specifi cations without prior notice. It is our policy to continuously develop and improve our products, therefore, we reserve the right to amend specifi cations without prior notice.
Seeger - Ring
Template fi xture
A
1. 7.
5.
3. 9.
2. 8.
6.
4. 10.
Remove the suction strainer Remove the fl ange.
Losen the pre-load charge by undoing screws “A”. It is not
necessary to remove the screws.
Pull out the complete electric connector. Position the fi xture on the pump as shown in the picture.
Unscrew the power cable gland. (Do the same for the
fl oater level control cable where present) Remove the O-Ring.
Remove the seeger-ring.
Undo the connection by pulling the two connectors apart. Turn the pump up side down and remove the outside
stainless steel sleeve.
