ENMET Corporation O ZONE G ENERATOR
6
Ozone Output Adjustment:
If the output is not the required level:
Verify that the flow meter is set to 0.5 lpm.
When the Ozone output is close to the desired concentration, adjustment should be made by a change in the position of
the glass tube. This can be made by single turns of the knurled adjustment collar. Pushing the glass tube in decreases
Ozone output and pulling the glass tube out increases the Ozone output.
C AUTION : Small changes to the position (length of exposed lamp) will greatly affect the output of the generator.
Loosen the retaining knurled collar on the ozone generator light (blue light).
ƒ If the level of output is low, pull the glass tube out slightly.
ƒ See section on verification of Ozone output.
ƒ If it is too high, push the glass tube in slightly.
ƒ See section on verification of Ozone output.
Tighten the retaining ring on the generator light.
Allow the generator to stabilize for at least 60 minutes and repeat the verification steps.
When output level is correct apply Ozone to monitor.
N
OTE : A sample draw system is used with the ENMET Ozone monitors. The sample bag must be in place during
monitor calibration.
(See Figure 2: Ozone Generator out to sample bag, sample bag out to sample draw system.)
Replacement Part Numbers
ENMET replacement part numbers:
Description Part Number
Ozone Generator 04052-009
Tubing (per inch) 73073-000
Pump Kit, for Detector Tube 90000-111
Detector Tube, Ozone (box of 10) 90182-200
Gas Bag, (2 liter, 2 valve) 04052-014
