4.0 Display Settings
To display the current settings of the GS-24-DF use the push button switches. See figures 1 and 2 for
location of switches.
Access the M
ENU and S ELECT switches through holes in front. See figures 1 and 2.
To cycle through the display settings press:
M ENU switch once = Low Flow alarm setting.
M ENU switch twice = High Flow alarm setting.
M ENU switch three times = Audio alarm on or off.
M ENU switch four times = Raw sensor signal in millivolts.
To disable audio alarm press:
S ELECT switch once = Audio Alarm (horn) disabled for approximately 1 minute.
4.1 Changing Display Settings
To change the current setting of the GS-24-DF use the push button switches.
Press and hold M ENU switch for three seconds, display will indicate Units
Press M ENU switch again, once for each setting: SET LO, SET HI, Set audio or Display menu.
When Units is displayed: Press S ELECT switch to change value.
Press M ENU switch to step through the values: LPM, CCM, CFM
Press S ELECT switch to exit, Display steps to SET LO
When SET LO is displayed: Press S ELECT switch to display the value.
Press M ENU switch to change the value.
Press S ELECT switch to Exit
When SET HI is displayed: Press S ELECT switch to display the value.
Press M ENU switch to change the value.
Press S ELECT switch to Exit
When SET AUD is displayed: Press S ELECT switch to display On or Off.
Press M ENU switch to change
Press S ELECT switch to Exit
When DISPLAY is displayed: Press S ELECT switch to display On or Off.
Press M ENU switch for Flow Dsp or Go/NoGo.
Press S ELECT switch to Exit
