Parts list – Elenco Deluxe Digital / Analog Trainer with Tools User Manual
Page 13
-12-
Qty.
Description
Part#
Resistors
2
100
Ω 5% 1/4W brn-blk-brn-gold
131000
10
120
Ω 5% 1/4W brn-red-brn-gold
131200
1
200
Ω 5% 1/4W red-blk-brn-gold
132000
1
220
Ω 5% 1/4W red-red-brn-gold
132200
2
330
Ω 5% 1/4W org-org-brn-gold
133300
5
1k
Ω 5% 1/4W brn-blk-red-gold
141000
2
1.2k
Ω 5% 1W brn-red-red-gold
141202
1
2k
Ω 5% 1/4W red-blk-red-gold
142000
2
4.7k
Ω 5% 1/4W yel-vio-red-gold
144700
1
6.8k
Ω 5% 1/4W blu-gry-red-gold
146800
1
8.2k
Ω 5% 1/4W gry-red-red-gold
148200
1
10k
Ω 5% 1/4W brn-blk-org-gold
151000
1
12k
Ω 5% 1/4W brn-red-org-gold
151200
3
22k
Ω 5% 1/4W red-red-org-gold
152200
1
47k
Ω 5% 1/4W yel-vio-org-gold
154700
1
51k
Ω 5% 1/4W grn-brn-org-gold
155100
16
100k
Ω 5% 1/4W brn-blk-yel-gold
161000
1
100k
Ω Pot Trim
191610
1
1k
Ω Pot PC Mount
192412
2
2k
Ω Pot PC Mount
192421
1
10k
Ω Pot PC Mount
192531
3
100k
Ω Pot PC Mount
192612
Capacitors
1
5pF 10% 50V Disc
205010
1
22pF 10% 50V Disc
212210
1
100pF 10% 50V Disc
221017
1
.001
μF 10% 100V Mylar
231017
1
.0022
μF 10% 50V Disc
232216
1
.01
μF 10% 100V Mylar
241017
4
.1
μF 10% 100V Mylar
251017
1
1
μF 50V Lytic Radial
261047
2
10
μF 25V Lytic Radial
271045
5
100
μF 25V Lytic Radial
281045
2
1000
μF 25V Lytic Radial
291045
4
1000
μF 35V Lytic Radial
291046
Semiconductors
19
1N4001 Diode
314001
2
1N4148 Diode
314148
2
2N3904 NPN Transistor
323904
1
2N3906 PNP Transistor
323906
1
LM317 Regulator
330317
1
LM318 Integrated Circuit
330318
1
LM337 Regulator
330337
1
XR2206 Integrated Circuit
332206
1
SN7403 Integrated Circuit
337403
1
LM7805 Regulator
337805
1
LM7812 Regulator
337812
1
LM7912 Regulator
337912
8
LED Red
350002
2
74HC04 Integrated Circuit 39HC04
Qty.
Description
Part#
Miscellaneous
1
Transformer
44K500
1
PC Board
514550
1
Fuse 1.25A
530125
10
Switch Slide PC Mount DPDT
541009
1
Switch Rocker Illuminated
541204
1
Switch Rotary 2P5POS
542206
1
Switch Rotary 4P3POS
542405
2
Connector 3-pin
591032
2
Connector 4-pin
591042
1
Connector 5-pin
591052
4
Bracket L 4-40 Tap
613008
1
Panel Top
614108
1
Frame
614501PB
9
Knob Push On
622009
1
Case
623051
1
Bushing Insulated
624003
1
Spacer Nylon 7/16” 4-40 Tap
624013
8
Spacer 1/4” #8 Plastic
624124
2
Screw #10-32 x 3/8” Hex
641158
1
Screw #4-40 x 1/4” Phil Flat
641431
9
Screw #4-40 x 1/4” Phil Truss
641438
6
Screw #6-32 x 3/8”
641640
4
Screw #4 x 1/4” Phil AB Blk
642430
4
Screw #6 x 3/8” Phil TC
642660
4
Screw #6 x 1/2” Phil AB Blk
642662
7
Nut Pot 7mm
644101
2
Nut Pot 9mm
644102
6
Nut #6-32 Hex
644601
2
Nut #10-32 Hex
644810
7
Washer Flat 8mm ID x 14mm OD
645101
2
Washer Flat 9mm ID x 15mm OD
645103
4
Washer Flat Black #6
645400
5
Washer Fiber #4
645404
2
Lockwasher #10 External
646910
1
Fuse Holder
663000
1
IC Socket 8-Pin
664008
3
IC Socket 14-Pin
664014
1
IC Socket 16-Pin
664016
18
Bredblox 4-Pin
665204
5
Insulator Mica
780002
5
Insulator Washer
780101
5”
Wire 20GA Red Top Coat
813120
2.5’ Wire 22GA Jumper
845000
1
Line Cord
862105
2”
Shrink Tubing 1/2” Dia
891101-2
2”
Shrink Tubing 3/4” Dia
899110-2
1
9426 Bredboard
99426
1
9830 Bredboard
99830
PARTS LIST
