ORGANIZER CARRYING CASE

The carrying case for the XK-700 Digital/Analog Trainer has been designed to hold a meter and many of the
most important tools. The layout below shows a suggestive layout for equipment and tools. For added storage
area, the tool palette has two sides; one with pockets and elastic as shown and the other with elastic.

When ordering a meter to be used with the XK-700 trainer, specify a PSV-50 kit which will provide you with
velcro to hold the meter in place. This is supplied FREE with meter order.

(TL-8) Precision screwdriver kit

(ET-10) IC puller

Calculator - see Elenco

®

catalog

(ST-75) 11 pc. driver set

(ST-1) Diagonal cutters

(ST-2) Long nose pliers

(SP-4) Desoldering pump

(LP-560) Logic probe

(ST-30) Deluxe wire stripper

(SE-1) Solder ease kit

(LF-99) Lead-free solder

(SW-3) Solder wick

(SR-2B) Deluxe soldering iron

(ST-20) Safety goggles

(SL-5) Deluxe soldering station

Meters - ANY of the
following will fit the
special slope cavity

Meters available:

...and others in catalog.

M-1700

M-1750

M-2795

M-2785

M-2666K

M-2625

LCM-1950

LCR-1810

M-1000D

Soldering station not included.
