Page 3
-2-
PARTS VERIFICATION
Before beginning the assembly process, familiarize yourself with the components and this instruction book.
Verify that all of the parts are present. This is best done by checking off the parts in the parts list.
RESISTORS
CAPACITORS
SEMICONDUCTOR
Electrolytic
(radial)
Potentiometer
Knob
MISCELLANEOUS
PC board
Case top
Case bottom
Screws
2.8 x 8mm
7mm
Nuts
Washers
Flat
8 x 14mm
Rubber foot
Label
Lead-free solder
Battery snap
Black wire 22ga.
Double-sided tape
XR-2206 Integrated
circuit (IC)
Rotary switch
DPDT switch
Binding posts
Black
Yellow
Binding post nut
Binding post
lockwasher
Battery holder
9mm
Flat
9 x 15mm
621
Chip
Chip
Electrolytic chip
