CONTROLS
RANGE SWITCHES
Six ranges of frequency are provided by the range switch as shown in Table 1.
Table 1
POSITION TYPICAL FREQUENCY RANGE
1 1Hz - 15Hz
2 10Hz - 150Hz
3 100Hz - 1.5kHz
4 1kHz - 15kHz
5 10kHz - 150kHz
6 100kHz - 1MHz
SINE/TRIANGLE SWITCH
This SINE/TRIANGLE Switch selects the waveform,
sine wave or triangle wave, sent to the
SINE/TRIANGLE output terminal.
FREQUENCY MULTIPLIER
The multiplier is a variable control allowing frequency
settings between fixed ranges. The ranges are as
shown in Table 1.
AMPLITUDE CONTROL
The Amplitude Control provides amplitude
adjustment from near 0 to 3V or greater for both sine
and triangle waveforms.
ON/OFF SWITCH
The ON/OFF Switch turns the power to the FG-600
on or off.
OUTPUT TERMINAL
The output marked SINE/TRIANGLE provides the
sine and triangle waveforms. The output marked
SQUARE WAVE provides the square wave. The
output marked GND provides the ground for all
output waveforms.
1) The heart of the FG-600 Function Generator is
the _________ monolithic function generator
integrated circuit.
2) The XR-2206 is comprised of four main blocks.
They are ____________________________,
___________________, __________________,
and ____________________.
3) The VCO actually produces an output frequency
proportional to an input ________________.
4) The current switches route one of the currents to
the VCO to produce an output __________.
5) The frequency is determined by the formula
_______________.
6) Frequency is inversely proportional to the value
of _____________.
7) The resistance between pins 13 and 14
determine the shape of the __________ wave on
pin 2.
8) No resistor produces a __________ wave.
9) A 200Ω resistor produces a ___________ wave.
10) The six ranges of frequency provided by the
range switch are:
________ to ________.
________ to ________.
________ to ________.
________ to ________.
________ to ________.
________ to ________.
QUIZ (answers on bottom of following page)
