Elenco Capacitor Substitution Box - Manual (Page 2)

PARTS LIST
If you are a student, and any parts are missing or damaged, please see instructor or bookstore.
If you purchased this capacitance box kit from a distributor, catalog, etc., please contact Elenco
TM Electronics
(address/phone/e-mail is at the back of this manual) for additional assistance, if needed.
CAPACITORS
Qty. Symbol Description Part #
1 R1 100pF (101) 50V 221017
1 R2 150pF (151) 50V 221510
1 R3 220pF (221) 50V 222210
1 R4 330pF (331) 50V 223317
1 R5 470pF (471) 50V 224717
1 R6 560pF (561) 50V 225610
1 R7 680pF (681) 50V 226880
1 R8 820pF (821) 50V 228210
1 R9 1000pF (102) 50V 231035
1 R10 1500pF (152) 50V 231516
1 R11 2200pF (222) 50V 232216
1 R12 3300pF (332) 50V 233310
1 R13 .0047
m
F (472) 50V 234710
1 R14 .0056
m
F (562) 100V 235618
1 R15 .0068
m
F (682) 50V 236810
1 R16 .0082
m
F (822) 100V 238218
1 R17 .01
m
F (103) 100V 241017
1 R18 .015
m
F (153) 100V 241517
1 R19 .022
m
F (223) 100V 242217
1 R20 .033
m
F (333) 100V 243317
1 R21 .047
m
F (473) 100V 244717
1 R22 .056
m
F (563) 100V 245618
1 R23 .068
m
F (683) 100V 246818
1 R24 .1
m
F (104) 100V 251017
MISCELLANEOUS
Qty. Description Part #
1 PC Board 517007
1 PC Mount Switch 541103
2 12 Position Switch 542013
2 Knob 622009
1 Case w/ Cover and Screws 62CS440
2 Nut 9mm 644102
2 Washer 9mm x 15mm 645103
1 Alligator Clip Black 680001
1 Alligator Clip Red 680002
12” Wire Black Stranded 814210
12” Wire Red Stranded 814215
1 Solder Tube 9ST4
-1-
The Capacitance Substitution Box is a convenient instrument in determining the desired capacitance values in
circuits under design or test. The values selected for your capacitance substitution box were determined to be
the most commonly used in modern solid-state circuits. The values are from 100pF to .1
m
F in 24 steps.
