BATTERIES:
Use only 9V alkaline type (not included).
Insert battery with correct polarity. Non-
rechargeable batteries should not be
recharged.
Rechargeable batteries
should only be charged under adult
supervision,
and should not be
recharged while in the product. Do not
mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
Remove batteries when they are used
up.
Do not short circuit the battery
terminals. Never throw batteries in a fire
or attempt to open its outer casing.
Batteries are harmful if swallowed, so
keep away from small children.
Important: If any parts are missing or damaged,
DO NOT RETURN TO RETAILER. Call toll-free
(800) 533-2441 or e-mail us at: [email protected].
Customer Service • 150 Carpenter Ave. • Wheeling,
IL 60090 U.S.A.
You may order additional / replacement parts
at our web site: www.snapcircuits.net
Qty. ID Name Part #
r 1 Stand 626100
r 1 Base grid 6SCBGM
r 2 1 1-snap wire 6SC01
r 3 2 2-snap wire 6SC02
r 1 3 3-snap wire 6SC03
r 1 5 5-snap wire 6SC05
r 1 B5 9V holder & SW 6SCB5
r 1 Q2 NPN transistor 6SCQ2
r 1 SP Speaker 6SCSP
r 1 U2 Alarm IC 6SCU2
r 1 U7 Motion detector 6SCU7
OTHER SNAP CIRCUITS PRODUCTS!
FM Radio
Model SCP-02
Music Box
Model SCP-04
Space Battle
Model SCP-05
Flying Saucer
Model SCP-06
PARTS LIST
Contact Elenco ® to find out where you can purchase these products.
Snap Circuits Jr. Model SC-100
Build over 100 projects, contains over 30 parts.
Snap Circuits Model SC-300
Build over 300 projects, contains over 60 parts.
Snap Circuits Pro Model SC-500
Build over 500 projects, contains over 75 parts.
Snap Circuits Extreme Model SC-750
Build over 750 projects, contains over 80 parts, and PC interface included.
Musical Recorder
Model SCP-01
Troubleshooting:
• If no sound is heard, then make sure your assembly is
correct and that all connections are securely snapped.
• If the motion detector never shuts off, or siren sounds
abnormal, then replace your batteries.
