Operator’s Manual
Chipper Shredders
ITEM #
PART #
DESCRIPTION
QTY.
1
1960507
BOLT, SOCKET BUTTON HD, 1/4-20
X 3/4
10
2
1098100
RETAINER, HOPPER GUARD
1
3
1095100
GUARD, HOPPER
1
4
1930642
NUT, FLANGE, 2-WAY LOCK, 1/4-20
14
5
1709603
SUPPORT, HOPPER GUARD
1
6
3621100
HANDLE
1
7
1919326
WASHER, PLAIN,
17/64 X 5/8 X 3/64
8
8
1931277
NUT, WHIZ, 5/18-18
18
9
3550841
CHIPPER CONE ASSEMBLY, METAL
(OPTIONAL)
1
10
1709469
HOPPER, RED
1
11
2005612
SAFETY GOGGLES
1
12
1926106
CAP SCREW, HEX,
5/16-18 X 3-1/4 GR5
1
13
3685100
DEFLECTOR
1
14
1709556
DEFLECTOR, FIXED
(EUROPEAN MODELS)
1
15
1960519
NUT, PUSH, 1/2
2
16
1714252
WHEEL & TIRE ASSEMBLY,
11 X 1.75
2
17
1924361
WASHER, PLAIN,
17/32 X 1-1/4 X 5/64
2
18
1928635
SCREW, TAPTITE,
3/8-16 X 1-1/4
4
19
1713099
KICKSTAND ROD
1
20
1925205
CAP SCREW, HEX,
5/16-18 X 5/8
1
21
1917356
LOCK WASHER, 5/16
10
22
1713281
ENGINE PLATE ASSEMBLY (ROTOR
HOUSING)
1
22A
4321
ADAPTER PLATE (9050300 & 9050140
ONLY)
1
23
-
ENGINE, 8.25 TORQUE RATED BRIGGS
CE (9060140)
1
-
ENGINE, 8.50 TORQUE RATED BRIGGS
INTEK HORZ SHAFT (9060300)
1
-
ENGINE, 11.50 TORQUE RATED
BRIGGS (9070300)
1
-
ENGINE, 14.50 TORQUE RATED
BRIGGS CE (12547)
1
ITEM #
PART #
DESCRIPTION
QTY.
23
-
ENGINE, 14.50 TORQUE RATED
BRIGGS INTEK (9010400)
1
-
ENGINE, 212CC VIPER (14267 &
14268, 19307)
1
24
1709403
COLLECTION BAG, 24" X 36"
1
25
1713203
PLATE, ENGINE KICKSTAND
1
26
1921515
CAP SCREW, HEX HD,
5/16-24 X 3/4
4
27
1960506
BOLT, SOCKET BUTTON HD, 1/4-20
X 7/8
4
METAL CONE ASSEMBLY PARTS
28
8930B
BOLT, 1/4X3/4 HH GR5 BLK ZN
4
29
3550813
PANEL, CONE TOP FLANGE
1
30
3550840
COVER, CONE FLAP
1
31
3550815
WELDMENT, CONE
1
32
48752B
NUT, FLANGED, TOP LOCK 1/4-20
4
33
3550814
PANEL CONE TOP EURO
EUROPEAN MODELS ONLY
1
ADDITIONAL PARTS NOT SHOWN
ITEM #
PART #
DESCRIPTION
QTY.
-
1709480
BASE PLATE, ENGINE
1
-
1713200
SPACER, BRIGGS ENGINE
1
-
1713201
PLATE, KICKSTAND, BRIGGS ENGINE
1
1713203
PLATE, KICKSTAND, BRIGGS ENGINE,
14.50 TORQUE RATED
1
-
1732039
DECAL, DANGER (U.S. VERSION)
CONE
1
-
1731920
DECAL, DANGER (CE EUROPEAN
VERSION) CONE
1
-
1732181
DECAL, DANGER (U.S. VERSION)
1
-
1731921
DECAL, DANGER (CE EUROPEAN)
1
-
LBL200201 DECAL, EARTHQUAKE DASH
1
ILLUSTRATED PARTS BREAKDOWN - HOPPER AND ENGINE GROUP
