Dynavector P-75 - Manual (Page 2)

Dynavector P-75
phono pre-amplifier
& phono enhancer
instructions & specifications
The P-75 has a unique power supply that runs at over 1/4MHz.
It takes the low grade single voltage DC supply from the ac
adapter and converts it to the dual high voltages required for true
professional quality audio reproduction. The operating frequency
is over 12 times higher than the top of the audio band and it
incorporates super low noise wideband regulators in its output
stage to give ultra low noise supply rails.
The internal P-75 power supply is totally self contained and stores
many times the maximum possible energy requirements for the
phono amplifiers. This means that the quality or size of the external
ac adaptor is irrelevant. Increasing the capacity of the external
supply will make no difference to the quality of the sound.
The P-75 incorporates the unique current amplifier invented by
Dr Tominari of Dynavector Systems Ltd., Japan, called a Phono
Enhancer.
Note: The P-75 supply requires a higher peak current to start up
and so we do not recommend using an adaptor of less than
500mA.
The P-75 does not have any mains frequency or other low
frequency components in the power supply and so hum problems
that plague conventional phono amplifiers are eliminated.
An earth terminal is provided on the rear panel that will allow the
metal chassis to be connected to earth if required.
While the P-75 itself does not generate any hum, the tone arm
and interconnect cables may act as antennae and pick-up some
hum. This is normally removed by running an earth wire to the
pre amplifier ground.
In some applications, the P-75 may need to be earthed.
IMPORTANT SAFETY INSTRUCTIONS
Read Instructions
All the safety and operating instructions should be read before using
this product.
Retain Instructions
The safety and operating instructions should be retained for future
reference.
Heed warnings
All warnings on the product and in the operating instructions should be
adhered to.
Follow instructions
All operating and use instructions should be followed.
Cleaning
Unplug the product from the wall outlet before cleaning. Do not use
liquid or aerosol cleaners. Use a damp cloth for cleaning.
Power sources
This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power
supply, consult your dealer.
Servicing
Refer all servicing to qualified service personnel.
Warranty
Dynavector manufactures its products to very high standards and we
are confident our products will perform well. Accordingly, we warrant
the Dynavector P-75 against manufacturing defects in material and
workmanship to the original owner, for a period of one year from the
original date of purchase. This warranty does not extend to damage
caused by improper use/installation, faulty ancillary equipment,
modifications, unauthorised repair, shipping damage or loss, abuse,
accidents, use on improper voltage/current, lightning or other acts of
God, normal wear and tear, commercial use, or puchases from
unauthorised dealers. Proof of purchase as evidence the unit was
purchased from an authorised dealer within the warranty period may
be required for warranty service.
Do not return the product without first
contacting your dealer or Dynavector. This warranty is non-transferable.
www.dynavector.com
Designed and manufactured by
Dynavector Australia and New Zealand / Aotearoa
4/05
