Remove Boiler Jacket
1.
Unscrew screws (A).
2. Pivot jacket upwards. See fi gure 3.
3. Raise Jacket up and off boiler. See fi gure 4.
1
3
2
A
A
Figure 3 - Jacket Removal - Screw
Locations
Figure 4 - Pivot Jacket and Raise to Remove
WARNING
Fire, explosion, asphyxiation and electrical
shock hazard. Disconnect electrical power
supply and turn off gas at shutoff valve before
attemting to remove boiler jacket. Failure to
follow these instructions could result in death
or serious injury.
!
