PL3200 PlasmaLift
Control Interface
Low-Voltage Control Lines:
There are three integrated methods of control and two optional methods. The standard
controls are three momentary buttons (contacts) or low-voltage control signal, or
single-latching contact. The optional methods are remote IR or RF control. Please
contact DDI for information on those options.
Three button control:
‘Home’ button (BLACK) Pin 6
‘Show’ button (RED) Pin 5
‘Stop’ button (GREEN) Pin 1
Common for all (WHITE) buttons Pin 4
Low voltage (5 vdc < V < 24 vdc) control signal:
Jumper Pin 6 to Pin 4, and jumper Pin 5 to Pin 4
Trigger Voltage to Pin 2
Trigger Voltage ground Pin 4.
(applied voltage sends lift up, no voltage sends lift down)
Single latching contact:
Jumper from Pin 6 to Pin 4, and jumper Pin 5 to Pin 4
Contacts between Pin 3 and Pin 2
(contact closed sends lift up, contact open sends lift down)
4 3 2 1
8 7 6
Control Box
Side View
