Display Devices PL-3000 Series Flat Screen Lifts Ceiling User Manual
Page 3

Cable Management
12.) Operate the lift up and down a few times to be sure that are no cables
binding anywhere on the lift.
13.) Verify that when the door is shut it is level with the unit frame, if not adjust
the all-thread arms on the left and right sides as needed.
Begin at fixed pivot point
Begin at fixed pivot point
Loop under
Loop under
Loop over
End point
