Installation Maintenance Notes:
Inspect and clean the air filter after two weeks of operation. The frequency of cleaning will be
dependent upon the environment the enclosure is located in (i.e., dust, leaves, etc.). Loosen the
captive screw on the front of the AC side. Let the hold down tab rotate. Pull the filter out to
inspect and clean. After cleaning reinsert – be sure it is settled within the track – flip latch up
and tighten captive screw.
Upon powering up the unit the compressor will not activate for 5 minutes. Any time power is
interrupted to the enclosure the air conditioning compressor has a 5 minute warm up time.
If the enclosure is mounted at less than a 10° angle (forward tilt) you will need to readjust the
angle of the compressor. A sticker on the front of the compressor access panel shows the angle
of adjustment. Loosen the nut and then adjust the angle reading to the angle the enclosure is
mounted at.
Loosen to adjust compressor
