5 Connect the AUX audio cable and the iPod docking cable to the interface unit. If an additional audio device will also
be used (mp3, DVD player, etc.) connect its audio cable to the 1/8” mini-jack. Apply cable ties to secure the cables.

power/antenna cable

iPod docking cable

receptacle

receptacle

6

T

Verify that all connections have been properly made.

7 Reconnect the car's battery. est the unit before seating the cables and reinstalling the panels/trim.

13

iPod

dock input

power

adapter

input

1/8”

mini-jack
