ATTACH THE LAT ATTACHMENT TO THE SMITH MACHINE USING THE M10 x 100MM
BOLTS (Q), 4” FLANGE PLATES (H), M10 WASHERS (U) AND M10 LOCKNUTS (T).
MAKE SURE ALL THE BOLTS ARE TIGHT BEFORE USE. REMEMBER TO CHECK THEM
PERIODICALLY TO MAKE SURE THEY ALWAYS STAY TIGHT.
FINAL INSTALLATION
T
T
U
U
U
U
Q
Q
H
H
H
H
U
U
U
U
T
T
Q
Q
