Gb w v h – Deltech Fitness DF4900L- Linear Bearing Smith Machine with Lat Attachment User Manual
Page 14
TOOLS REQUIRED:
METRIC WRENCHES OR SOCKET SET
INSTALL THE REAR SUPPORT (G) TO THE BOTTOM SUPPORT (B), ALIGNING HOLES IN
FLANGE WITH PIN AND THREADED STUD. INSTALL 12MM WASHER (W) AND 12MM NUT
(V) AND TIGHTEN.
INSTALL THE FRONT SUPPORT (H) TO THE BOTTOM SUPPORT (B), ALIGNING HOLES IN
FLANGE WITH PIN AND THREADED STUD. INSTALL 12MM WASHER (W) AND 12MM NUT
(V) AND TIGHTEN.
FRAME ASSEMBLY
G
B
W
V
H
