19 ALPHA SPOT HPE 1500 & ST
Tilt Home Def Pos
Lets you assign the Tilt channel “home” position at the end of Reset,
without a DMX input signal.
1) Press
F , the current setting appears on the display.
2) Use the UP B and DOWN C keys to select one of the following
settings:
0%
12.5%
25%
50% (default)
75%
87.5%
100%
3) Press F to confirm the selection or LEFT D to keep the current
setting.
COLOR
Color mixing
Used for reversing the CMY color mixing system.
1) Press
F - the current settings appear on the display (On or Off).
2) Use the UP B and DOWN C keys select one of the following settings:
RGB color mixing mode
CMY color mixing mode
3) Press F to confirm the selection or LEFT D to keep current settings.
Fixed wheel short-cut
Used for optimizing color change time so that the disc turns in the direc-
tion that requires shorter movement.
1) Press
F – the current settings appear on the display (On or Off).
2) Use the UP B and DOWN C keys to enable (On) or disable (Off)
color change optimization.
3) Press F to confirm the selection, or LEFT D to keep current settings.
Macro color adjustment
It lets you enable the overwriting of a “Macro Colour” with the Cyan,
Magenta, Yellow, CTO and Colour wheel channels.
Press
F the current setting appears on the display.
1) Use the UP B and DOWN C keys to enable (On) or disable (Off)
the overwriting.
2) Press F to confirm the selection or LEFT D to keep the current setting.
SHUTTER
Shutter on error
Used for automatically closing the stop/strobe in the event of Pan/Tilt
position error.
1) Press
F - the current settings appear on the display (On or Off).
2) Use the UP B and DOWN C keys to enable (On) or disable (Off)
automatic stop/strobe closing in the event of Pan/Tilt position error.
3) Press F to confirm the selection, or LEFT D to keep current settings.
Dimmer on Shutter
Enables automatic closing of the dimmer when the strobe is completely closed.
1) Press
F – the current settings appear on the display (On or Off).
2) Use the UP B and DOWN C keys to enable (On) or disable (Off)
the automatic closing of the dimmer.
3) Press F to confirm the selection or LEFT D to keep current settings.
AUTO-FOCUS MODE
It lets you select the “Auto-focus Mode” from the two available.
1) Press
F the current setting appears on the display.
2) Use the UP B and DOWN C keys to select one of the following settings:
Limited Zoom Range: The “Autofocus” works only in the optical run
that was specifically designed for the projector in question.
Complete Zoom Range: The “Autofocus” also works in overrun
3) Press F to confirm the selection or LEFT D to keep the current setting.
Shutter
Shutter
On Error
On
Off
Dimmer On
Shutter
On
Off
Auto-focus
Mode
Limited
Zoom Range
Complete
Zoom Range
Color
Color
Mixing
RGB
CMY
Fixwheel
Shortcut
On
Off
Macro Color
Adjustment
On
Off
Option Pan / Tilt
Tilt Home
Def Pos
Continue ➔
