www.desatech.com 111250-01E 41
KEY
NO. PART NO.
DESCRIpTION QTY.
1 11102 Screw #8-32 x 3/8 PPH Zinc 2
2 11105 Screw #10 x 1/2 Zinc 9
3 11179 Screw #10-24 x 1/4 Zinc 4
4 11237 Screw, Trilab M4 x 8 mm 1
5 14389 Millivolt Valve (Natural) 1
14390 Millivolt Valve (Propane/LP) 1
6 14492 Piezo Ignitor 1
7 14500 Brass Fitting 2
8 14508 Flexible Connector 1
9 14511 Ignitor Bracket 1
10 14528 Brass Elbow Fitting 1
11 14496 Orifice (Natural) 1
14514 Orifice (Propane/LP) 1
12 110984-01 Aluminum Tubing Assembly 1
13 26808 Valve Bracket 1
14 26827 Switch Bracket 1
15 108007-01 Base Grate Assembly 1
16 104504-03 Burner 1
17 108084-02 Pilot Assembly (Natural) 1
108084-03 Pilot Assembly (Propane/LP) 1
18 110996-01 Burner Base Assembly 1
19 110986-01 Air Baffle (Natural) 1
110986-02 Air Baffle (Propane/LP) 1
PARTS LIST
BURNER FOR MODELS (V)T36NA, (V)T36NBA, (V)T36NRA, (V)T36NRBA,
(V)T36PA, (V)T36PBA, (V)T36PRA, (V)36PRBA AND CTDV36NRA
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 36 of this manual.
