PARTS LIST
MODELS (V)T36NA, (V)T36NBA, (V)T36NRA, (V)T36NRBA, (V)T36PA,
(V)T36PBA, (V)T36PRA, (V)36PRBA AND CTDV36NRA
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 36 of this manual.
KEY
NO.
PART NO.
DESCRIpTION
QTY.
1
**
Firebox Assembly
1
2
**
Face Weldment
1
3
108010-01
Door Assembly, T & CTDV Models Only
1
108010-02
Door Assembly, VT Models Only
1
4
108687-01
Top Panel Louver Assy, T36NA/PA, T36NBA/PBA Models
1
108011-01
Top Rolled Louver Assy, T36NRA/PRA, T36NRBA/PRBA &
CTDV36NRA Models
1
5
108687-02
Bottom Panel Louver Assy, T36NA/PA, T36NBA/PBA Models
1
108011-02
Bottom Rolled Louver Assy, T36NRA/PRA, T36NRBA/PRBA &
CTDV36NRA Models
1
6
108015-01
Fireplace Top
1
7
**
Fireplace Top Insulation
1
8
**
Fireplace Surround
1
9
108074-01
Burner Assembly (Natural) (See pages 40 and 41)
1
108074-02
Burner Assembly (Propane/LP) (See pages 40 and 41)
1
10
108076-01
Burner Base Gasket
1
11
see below
Rear Refractory Brick Panel
1
12
see below
Right Refractory Brick Panel
1
13
see below
Left Refractory Brick Panel
1
14
11418
Push-On Nut
2
15
12105
Screen
2
16
108719-01
Screen Rod
1
17
14123
Strain Relief
1
18
21171
Gas Knock-Out Cover
2
19
24353
Handy Box Assembly
1
20
24460
Gas Conduit Assembly
1
21
109082-01
Heat Shield
1
22
109006-01
Log Set
1
22-1 109007-01
Rear Log (Log 1)
1
22-2 110182-01
Front Log (Log 2)
1
22-3 109008-01
Crossover Log (Log 3)
1
22-4 107347-01
Right Top Log (Log 4)
1
22-5 109009-01
Base Log (Log 5)
1
22-6 107348-01
Left Top Log (Log 6)
1
PARTS AVAILABLE - NOT SHOWN
25487
Lava Rock/Bag Assy
1
27253
Notice Label
1
55240
Vent Label
1
PCDM-36TA Conversion Kit (CTDV36NRA only)
1
** Not a field replaceable part.
(V)T36NA
(V)T36NRA
(V)T36PA
(V)T36PRA
T36NBA
T36NRBA
T36PBA
T36PRBA
VT36NBA
VT36NRBA
VT36BA, V36PRBA
CTDV36NRA
DESRIpTION
QTY.
—
110991-02
110991-01
Rear Refractory Brick Panel
1
—
110990-02
110990-01
Right Refractory Brick Panel
1
—
110989-02
110989-01
Left Refractory Brick Panel
1
