I NSTALLATION / M AINTENANCE I NSTRUCTIONS
H
2
Optimiser
Introduction
Your new Bonaire Integra has been fitted with an H
2
Optimiser water
management system. This H
2
Optimiser is designed to give increased water
savings through controlled management of the maintenance water.
All units using conventional bleed and dumping systems require regular
bleeding or dumping of the water during each day. With the H
2
Optimiser
Water Management system, water can be held for much longer periods of
time before being released conserving up to 45% of water usage.
This is achieved by using the CARE-FREE Water Conditioner A/C 6 in the
water distribution circuit. The CARE-FREE Water Conditioner A/C 6 disrupts
the cohesion of dissolved solids reducing the opportunity for scale
precipitation.
The H
2
Optimiser will only operate successfully when dissolved solids in the
water does not exceed 300 parts per million.
Set Up
Very little is required to set up the H
2
Optimiser. 2 dip switches in the control
box set the water drain cycle times suitable to the dissolved solids in the
water. The unit comes from the factory with the water drain cycle times preset.
The drain cycle dip switches are located inside the unit control box.
To check the correct setting has been applied, see the table below.
NOTE: Isolate the power to the control box before opening the control
box lid.
Maximum Pump Runtime Between Drain Cycles.
Dip Switches 100ppm 200ppm 300pm
Large 28hrs 23 hrs 16 hrs
Medium 33hrs 27 hrs 18 hrs
Small 48hrs 40 hrs 27 hrs
Page 2
