User ’s Manual
ESM-QM77B User ’s Manual 9
1.5 System Specifications
System
CPU On board Intel Core i7/i5/i3/Celeron (FCBGA1023) Processors
BIOS AMI 64M-bit SPI BIOS
System Chipset Intel QM77 Chipset
System Memory Two 204-pin DDR3 SODIMM socket, supports up to 16GB DDR3 1333/1600 SDRAM
Expansion 7 PCIe x1, 1 PCIe x16
I/O
MIO 4 x Serial ATA ports, SMbus
USB 8 x USB 2.0 , 4xUSB 3.0ports
DIO 4-bit GPI, 4-bit GPO
Display
Chipset Intel QM77 Chipset Integrated
Memory DVMT 5.0 up to 512MB
Resolution
CRT Mode: 2048 x 1536
LCD/ Simultaneous Mode: 1920 x 1200
LVDS Dual channel 18/24-bit LVDS
Display Supported HDMI, DVI, Display Port
Audio
Chipset Intel QM77 integrated
Interface Intel High Definition Audio
Ethernet
LAN Chip Intel 82579LM
Ethernet Interface 10/100/1000 Base-Tx Gigabit Ethernet Compatible
Mechanical &
Environmental
Power
Requirement
+9~ +19V
ACPI
Single power ATX Support S0, S3, S4, S5
ACPI 3.0 Compliant
Power Type AT/ATX
Operating Temp. 0 to 60

C
Storage Temp. -40~-75°C
Operating
Humidity
0%~90% relative humidity, non-condensing
Size (L x W) 125 mm x 95 mm
Weight 0.44lbs(0.2kg)
