User ’s Manual
ESM-QM77B User ’s Manual 51
Item Option Description
EIST
Disabled
Enabled[Default]
Enable or Disable Intel
SpeedStep.
Turbo Mode Turbo Mode.
CPU C3/6/7 Report
Enable or Disable CPU C3(ACPI
C2)/6(ACPI C3)/7(ACPI C3)
report to OS.
Configurable TDP
TDP NOMINAL[Default]
TDP DOWN
TDP UP
Disabled
Allow reconfiguration of TDP
levels base on current power and
thermal delivery capabilities of the
system.
Config TDP LOCK
Disabled[Default]
Enabled
Lock the Config TDP Control
register.
Long duration power limit Long duration power limit in Watts, 0 means use factory default.
Long duration maintained Time window which the long duration power is maintained.
Short duration power limit Short duration power limit in Watts, 0 means use factory default.
ACPI T State
Disabled[Default]
Enabled
Enable/Disable ACPI T state
support.
3.6.3 Chipset
