ESM-QM77B
58 ESM-QM77B User ’s Manual
1024x600 18/1
800x600 18/1
1600x1200 24/2
1366x768 24/1
1680x1050 24/2
1920x1200 24/2
1440x900 24/2
1600x1200 24/2
1024x768 24/1
1280x800 18/1
1920x1080 24/2
2048x1536 24/2
Spread Spectrum clock Chip
Off[Default]
Hardware
Software
>>Hardware : Spread is controlled
by chip;>>Software : Spread is
controlled by BIOS.
ALS Support
Disabled[Default]
Enabled
Valid only for ACPI. Legacy= ALS
Support through the IGD INT10
function. ACPI= ALS support
through an ACPI ALS driver.
Active LFP
No LVDS
Int-LVDS[Default]
SDVO LVDS
Select the Active LFP
Configuration. No LVDS: VBIOS
does not enable LVDS. Int-LVDS:
VBIOS enables LVDS driver by
Integrated encoder. SDVO LVDS:
VBIOS enables LVDS driver by
SDVO encoder. eDP Port-A: LFP
Driven by Int-DisplayPort encoder
from Port-A. eDP Port-D: LFP
Driven by Int-DisplayPort encoder
from Port-D (through PCH).
