EQM-CDV
42 EQM-CDV User ’s Manual
Active LFP
No LVDS
Int-LVDS (eDP-7511)
Select the Active LFP
Configuration.
No LVDS: VBIOS does not enable
LVDS.
Int-LVDS: VBIOS enables LVDS
driver by integrated encoder.
SDVO LVDS: VBIOS enables
LVDS driver by SDVO encoder.
eDP Port-A: LFP Driven by
Int-DisplayPort encoder from
Port-A.
eDP Port-D: LFP Driven by
Int-DisplayPort encoder from
Port-D (through PCH).
CH7511 EDID Panel Option
1024x768 24/1
800x600 24/1
1024x768 18/1
1024x576 18/1
1024x600 18/1
1280x800 18/1
1920x1200 18/2
640x480 24/1
800x480 24/1
1280x768 24/1
1280x1024 24/2
1440x900 24/2
1600x1200 24/2
1366x768 24/1
1920x1080 24/2
1680x1050 24/2
Port1-EDP to LVDS (Chrotel
7511) Panel EDID Option.
LVDS Back Light PWM
00%
25%
50%
75%
100%
Select LVDS backlight PWM duty
LVDS Back Light PWM
Frequency
175
230
350
700
1k / 2k / 3k / 5k
10k / 20k / 30k / 50k / 100k
Select LVDS backlight PWM
frequency
IGD Clock Source
External clock
Internal clock
IGD clock selection
Fixed Graphics Memory Size
128MB
256MB Configure Fixed Graphics
memory Size
ALS Support
Enabled
Disabled
Valid only for ACPI.
Legacy=ALS Support through the
IGD INT10 function.
ACPI=ALS support through an
ACPI ALS driver
BIA
Auto
Disabled
Level1/2/3/4/5
Auto: GMCH Use VBT Default;
Level n: Enabled with Selected
Aggressiveness Level.
EAP-OPT Delay
Disabled
1/2/3/4/5sec
EAP-OPT Delay for HDMI
