EQM-CDV User ’s Manual 11
1.4 System Specifications
System
CPU Onboard Intel CDV-M N2600 1.6GHz or N2800 1.86GHz CPU
BIOS AMI 16M-bit SPI BIOS
System Chipset Intel NM10 Express Chipset
I/O Chip N/A
System Memory Onboard DDR3 800/1066, up to 2GB DDR3 800/1066 SDRAM
SSD N/A
Watchdog Timer Reset: 1 sec.~65535 sec./min. and 1 sec. or 1 min./step
H/W Status
Monitor
Monitoring system temperature, voltage. Auto trotting control when CPU
overheats
Expansion LPC, SMBus, HD audio I/F
I/O
MIO 2 x SATA ports to baseboard
USB 8 x USB 2.0 ports to baseboard
IrDA N/A
External I/O Connector Qseven spec 1.2 connector for expansions
Display
Chipset Intel Cedarview integrated graphics
Resolution
HDMI mode: 1920 x 1200 @ 60Hz
LCD/Simultaneous mode : 1366 x 768 @ 60 Hz (CDV-M)
Multiple
Display
HDMI + LVDS to baseboard
LCD
Interface
Single channel 18 bit LVDS
TV-out N/A
Built-in Touch Screen (Optional)
Audio
AC97 Codec N/A
Audio Interface N/A
Ethernet
LAN Chip
1 x Intel 82574L Gigabit Ethernet
Ethernet Interface
10/100/1000 Base-Tx Gigabit Ethernet Compatible
