Avalue EPS-QM87 User Manual
Page 23
Quick Reference Guide
EPS-QM87 Quick Reference Guide 23
Signal
PIN PIN
Signal
GND
D31 C31
GND
DDI1_PAIR2+
D32 C32 DDI2_CTRLCLK_AUX+
DDI1_PAIR2-
D33 C33 DDI2_CTRLDATA_AUX-
DDI1_DDC_AUX_SEL
D34 C34
DDI2_DDC_AUX_SEL
NC
D35 C35
NC
DDI1_PAIR3+
D36 C36 DDI3_CTRLCLK_AUX+
DDI1_PAIR3-
D37 C37 DDI3_CTRLDATA_AUX-
NC
D38 C38
DDI3_DDC_AUX_SEL
DDI2_PAIR0+
D39 C39
DDI3_PAIR0+
DDI2_PAIR0-
D40 C40
DDI3_PAIR0-
GND
D41 C41
GND
DDI2_PAIR1+
D42 C42
DDI3_PAIR1+
DDI2_PAIR1-
D43 C43
DDI3_PAIR1-
DDI2_HPD
D44 C44
DDI3_HPD
NC
D45 C45
NC
DDI2_PAIR2+
D46 C46
DDI3_PAIR2+
DDI2_PAIR2-
D47 C47
DDI3_PAIR2-
NC
D48 C48
NC
DDI2_PAIR3+
D49 C49
DDI3_PAIR3+
DDI2_PAIR3-
D50 C50
DDI3_PAIR3-
GND
D51 C51
GND
PEG_TX0+
D52 C52
PEG_RX0+
PEG_TX0-
D53 C53
PEG_RX0-
PEG_LANE_RV#
D54 C54
NC
PEG_TX1+
D55 C55
PEG_RX1+
PEG_TX1-
D56 C56
PEG_RX1-
TYPE2#
D57 C57
NC
PEG_TX2+
D58 C58
PEG_RX2+
PEG_TX2-
D59 C59
PEG_RX2-
GND
D60 C60
GND
Signal
PIN PIN
Signal
PEG_TX3+ D61 C61 PEG_RX3+
PEG_TX3- D62 C62 PEG_RX3-
NC
D63 C63
NC
NC-
D64 C64
NC
PEG_TX4+ D65 C65 PEG_RX4+
PEG_TX4- D66 C66 PEG_RX4-
GND
D67 C67
NC
PEG_TX5+ D68 C68 PEG_RX5+
PEG_TX5- D69 C69 PEG_RX5-
GND
D70 C70
GND
PEG_TX6+ D71 C71 PEG_RX6+
PEG_TX6- D72 C72 PEG_RX6-
GND
D73 C73
GND
PEG_TX7+ D74 C74 PEG_RX7+
PEG_TX7- D75 C75 PEG_RX7-
GND
D76 C76
GND
NC
D77 C77
NC
PEG_TX8+ D78 C78 PEG_RX8+
PEG_TX8- D79 C79 PEG_RX8-
GND
D80 C80
GND
PEG_TX9+ D81 C81 PEG_RX9+
PEG_TX9- D82 C82 PEG_RX9-
NC
D83 C83
NC
GND
D84 C84
GND
PEG_TX10+ D85 C85 PEG_RX10+
PEG_TX10- D86 C86 PEG_RX10-
GND
D87 C87
GND
PEG_TX11+ D88 C88 PEG_RX11+
PEG_TX11- D89 C89 PEG_RX11-
GND
D90 C90
GND
