Quick Reference Guide
EPS-QM87 Quick Reference Guide 21
Signal PIN PIN Signal
VGA_GRN B91 A91 NC
VGA_BLU B92 A92 NC
VGA_HSYNC B93 A93 NC
VGA_VSYNC B94 A94 NC
VGA_I2C_CK B95 A95 NC
VGA_I2C_DAT B96 A96 NC
NC B97 A97 NC
NC B98 A98 NC
NC B99 A99 NC
GND B100 A100 GND
FAN_PWMOUT B101 A101 NC
FAN_TACHIN B102 A102 NC
NC B103 A103 NC
VCC_12V B104 A104 VCC_12V
VCC_12V B105 A105 VCC_12V
VCC_12V B106 A106 VCC_12V
VCC_12V B107 A107 VCC_12V
VCC_12V B108 A108 VCC_12V
VCC_12V B109 A109 VCC_12V
GND B110 A110 GND
