Quick Reference Guide

ERS-BYTE Quick Reference Guide 13

2.1.3

External Serial Port 5/6/7/8/9/10 connector (COM5/6/7/8/9/10)

Signal

PIN PIN

Signal

DCD

1

6

DSR

RXD

2

7

RTS

TXD

3

8

CTS

DTR

4

9

RI

GND

5

2.1.4

VGA connector (VGA)

PIN Signal PIN Signal PIN

Signal

1

RED

6

GND

11

NC

2

GREEN

7

GND

12 DDCDAT

3

BLUE

8

GND

13

HSYNC

4

NC

9

+5V

14

VSYNS

5

GND

10

GND

15 DDCCLK
