1.4 System Overview
1.4.1 Front View
Connectors
Label Function Note
POWER Power on button
USB USB 2.0 connector
MIC IN Mic-in audio jack
LINE IN Line-in audio jack
LINE OUT Line-out audio jack
1.4.2 Side & Rear View
Connectors
Label Function Note
COM1 Serial port 1 connector D-sub 9-pin, male
CF/DVI/COM2
Compact Flash card connector
DVI connector
Serial port 2 connector
HDD HDD indicator
LAN1 RJ-45 Ethernet 1
KB/MS/LAN2 RJ-45 Ethernet connector 2
Power
