Avalue ASM-BYT - Manual (Page 6)

ASM-BYT
6 ASM-BYT Quick Reference Guide
Chipset  2 x Intel® I211AT Gigabit Ethernet Controller
Ethernet Interface  10/100/1000 Base-Tx Gigabit Ethernet Compatible
Mechanical
Power Type  +12 ~ 26Vdc (Lockable DC Jack)
ACPI
 Single Power ATX Support S0, S3, S4, S5
 ACPI 3.0 Compliant
Power Mode  AT/ATX (ATX is the default setting)
Operating
Temperature
 0 ~ 50°C (32 ~ 122°F) (w/CF & SSD), Ambient w/Air Flow
 0 ~ 40°C (32 ~ 104°F) (w/HDD), Ambient w/Air Flow
Storage
Temperature
 -40 ~ 75°C (-40 ~ 167°F)
Relative Humidity  0% ~ 90% Relative Humidity, Non-condensing
Vibration
Protection
 With CF/SSD: 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 30min/axis
Shock Protection  With CF/SSD: 10G, IEC 60068-2-27, Half Sine,11ms
Certification  CE, FCC Class B
Dimension (W x H x
D)
 182mm x 257mm x 25mm
Weight  1.2kgs
Color  Silver and Black
Fanless  YES
Reliability
IP Rating  IP 30
