Quick Reference Guide
ASM-BYT Quick Reference Guide 5
1.3 System Specifications
System
Board  EBM-BYT
CPU  Intel® Celeron® Processor J1900 Family
BIOS  AMI uEFI BIOS, 64/128Mbit SPI Flash ROM
System Chipset  Valleyview D SoC Integrated
I/O Chipset  EC (IT8528E)
System Memory  One 204-pin SODIMM Socket Up to 8GB DDR3L 1333 SDRAM
Watchdog Timer  H/W Reset, 1sec. ~ 65535sec./1sec.step
H/W Status
Monitor
 Monitoring System Temperature, Voltage with Auto Throttling Control
Storage
Solid State Drive  1 x CF, 1 x SATA, 1 x mSATA
External I/O
COM Port
 2 x COM Port supports RS-232/422/485
 COM1 can be set as RS-422/485 via BIOS
 COM2 can be set as RS-422/485 via DIP Switch
USB Port  4 x USB (2 on front side; 2 on rear side)
Video Port  1 x VGA, 1 X HDMI
Audio Port  Mic-In, Line-Out, Line-In
LAN Port  2 x RJ45
Switch  1 x Power on/off
Indicator Light
 1 x Power on/off LED on the rear side
 1 x Storage LED on the rear side
CF  1 x CompactFlash Type I/II Socket w/ Cover
Antenna  1 x Knockouts for antenna mounting
Expansion Slots
 1 x Mini PCIe with SIM CArd
 1 x Mini PCIe supports mSATA
Display
Chipset  Intel® Celeron® SoC Integrated Graphics
Multiple Display  Dual Display, HDMI + LVDS
Resolution
 VGA Mode: 2560 x 1600 @ 60Hz
 HDMI Mode: 1920 x 1200 @ 60Hz
Audio
HD Codec  Realtek ALC892 Supports 5.1-CH Audio
Audio Interface  Mic-in, Line-in, Line-out
Ethernet
