EMX-CDD Quick Installation Guide
EMX-CDD Quick Installation Guide 7
Connectors
Label Function Note
FPANEL1 Front Panel Switches 2 x 8 header, pitch 2.54 mm
MPCIE_WIFI_SATA PCIE signal selector
HDMI1 HDMI connector
J1 ATX power connector for DC 12V input
JSPK Speaker connector 1 x 4 wafer, pitch 2.00 mm
J14 DC power-in connector 2 x 2 header, pitch 4.20 mm
JCOM1~6 Serial port 1~6 connector 2 x 5 header, pitch 2.00 mm
GPIO General Purpose I/O 2 x 6 header, pitch 2.54 mm
JLVDS1 LVDS connector 2 x 20 wafer, pitch 1.25 mm
SATA1~2 Serial ATA connector 1~2
SATA1~2_PWR SATA Power connector 1~2 1 x 4 header, pitch 2.54 mm
F_MIC1 Mic-in audio jack 3.5mm phone jack
F_OUT1 Line-out audio jack 3.5mm phone jack
RJ45LAN1~2 LAN port 1~2
F_USB1~3 USB connector 1~3 2 x 5 header, pitch 2.54 mm
USB1 USB connector
SFAN1 System Fan connector 1 x 3 wafer, pitch 2.54 mm
CFAN1 CPU Fan connector 1 x 4 wafer, pitch 2.50 mm
JLPT Printer 2 x 12 header, pitch 2.54 mm
DIMM1 DDR3 SODIMM socket
VGA1 VGA connector
JVGA VGA connector 2 x 5 header, pitch 2.54 mm
JINVERT1 Inverter connector 1 x 5 header, pitch 2.54 mm
KM1 Keyboard & Mouse connector 2 x 5 header, pitch 2.54 mm
F_AUDIO1 Front Panel Audio Connection Header 2 x 5 header, pitch 2.54 mm
JSPIDF1 Sony/Philips Digital Interface 1 x 5 header, pitch 2.54 mm
IRDA IRDA connector (not supported) 1 x 5 header, pitch 2.00 mm
